3-43
AIR COMPRESSOR SWITCH (option)
21)
110D9CD61
This switch is used to activate the air compressor.
(1)
SEAT HEAT SWITCH (option)
22)
110D9CD62
This switch is used to heat the seat.
(1)
This switch use to control the cooling fan.
This switch has three positions.
· AUTO : The fan automatically work in reverse according to set up
interval and time of the cooling fan reverse mode.
ö
Refer to page 3-29 to set of the cluster.
· OFF : Only forward rotation is possible.
· MANUAL : The fan rotates reverse only while pressing this
position.
If release the switch, return to the OFF position.
The reverse rotation pilot lamp lights up on the area of the
warning and pilot lamp of the LCD when the cooling fan is
operated to the reverse rotation.
(1)
(2)
(3)
ö
COOLING FAN CONTROL SWITCH (option)
23)
180D9CD63
