1-5
GROUP 2 SPECIFICATIONS
1. GENERAL LOCATIONS
9
10
17
16
15
14
13
21
18
19
20
1
2
3
4
7
6
5
8
11
12
15L7MOM57
1 Steering wheel
2 Mast
3 Lift chain
4 Lift cylinder
5 Cluster
6 Backrest
7 Carriage
8Forks
9 Tilt cylinder
10 Front wheel
11 Bonnet
12 Rear wheel
13 Counterweight
14 Seat
15 LPG tank
16 Clamp
17 Overhead guard
18 Rear combination lamp
19 Turn signal lamp
20 Head lamp
21 Sub bonnet

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hyundai 20L 7M and is the answer not in the manual?

Hyundai 20L 7M Specifications

General IconGeneral
CategoryForklifts
Rated Capacity2000 kg
Load Center Distance500 mm
Tyre TypePneumatic
Weight3200 kg
