Hyundai 35DS-7 User Manual

4-8
ASSEMBLY
The assembly must be carried out by following the so far described sequence but in reverse
or
der, taking great care not to assemble the new gaskets back to front or upside down.
3)
ö
12
13
14
15
16
17
15
33
9
11
9
10
2
35
20
34
31
32
30
28
27
26
25
29-1
29-2
29-3
29-4
29-5
29-6
29-7
29-8
29-9
8
20
18
19
21
22
23
24
7
1
3
4
5
6
D357BS07
SEAL KIT : ZTAX-00077
Use only brake fluid (Azola ZS10) in the compensation reservoirs.
Â

Hyundai 35DS-7 Specifications

General

Model	35DS-7
Category	Forklifts
Load Capacity	3500 kg
Power Source	Diesel
Lift Height	3000 mm
Mast Type	Duplex
Load Center	500 mm
Engine Power	50 kW
Fork Length	1070 mm
Tire Type	Pneumatic
Transmission	Automatic
Fuel Type	Diesel
Fuel Tank Capacity	70 liters
