1-2
Be particularly careful when removing the
radiator cap and the hydraulic oil tank filler
cap, if this is done immediately after using the
machine, there is a danger that boiled oil may
spurt out.
The procedure for releasing the hydraulic
pressure is as follows : lower the fork to the ground,
and stop the engine(Motor), move the control
levers to each position two or three times.
Â
When working on top of the machine, be
careful not to lose your balance and fall.
Â
Hand a caution sign in the operator's compartment
(For example
Do not start
or
Maintenance in
progress
).
This will prevent anyone from starting or
moving the machine by mistake.
It is extremely dangerous to try to check the
fan belt tension while he engine is running.
Â
When inspecting the engine is running parts,
or
near such parts, always stop the engine first.
Before checking or servicing accumulator or
piping, depress brake pedal repeatedLy to
release pressure.
Park the machine on firm, flat ground.
Lower the fork to the ground and stop the
engine.
Return each lever to
NEUTRAL
and apply
the brake lock.
Â
D50ASF05
D50ASF06
D50ASF07
D50ASF08
