10-4
FAN
Move fan backwards and forwards by hand
to check for looseness.
Tighten mounting bolt with a spanner.
FAN BELT
Check that fan belt is not damaged.
Check inside of belt also. If bottom of
pulley groove is shining, belt will slip so
replace.
Check deflection when fan belt is pushed
with a finger pressure at a point midway
between fan pulley and alternator pulley.
If fan belt tension is not correct, loosen
alternator mounting nut and bolt of
adjustment bar. Move alternator to adjust
belt tension.
Keep the fan belt free from oil and
grease so that it can prevent the fan
belt from sli
ppage.
(1)
(2)
(3)
(4)
ö
