6-1
GROUP 1 STRUCTURE AND FUNCTION
SECTION 6 HYDRAULIC SYSTEM
1. HYDRAULIC CIRCUIT
6
12
8
11
7
3
4
13
5
2
10
9
14
EF
CF
LS
T/M
TLSP
R
13.5 MPa
A1
A2
B1
B2
A3
E/G
From Axle
To Axle
18.5MPa
15MPa
P
T
4 MPa
24V
24V
1
1B
1A
2B
2A
3B
3A
4B 4A
GAGE PORT
L
50DS7EHS01
1 Hydraulic gear pump
2 Priority valve
3 Main control valve
4 Steering unit
5 Brake valve
6 Steering cylinder
7 Tilt cylinder
8 Lift cylinder
9 Suction filter
10 Return filter
11 Down control valve
12 Down safety valve
13 Accumulator
14 Hydraulic tank
