iB KOJAK - Flat Scanning; Finger Placement

11
FLAT SCANNING
FINGER PLACEMENT
Place hand firmly against the bezel to ensure proper contact.
· Kojak LEDs glow orange
· Place right hand firmly against the bezel
to ensure proper contact
· Kojak LEDs glow green when capture is complete
· Repeat process for left hand
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
Ready to Scan - Left Scan Complete - Left
Ready to Scan - Right Scan Complete - Right
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
ROLL
CAPTURE CAPTURE CAPTURE
Orange
LEDs
Green
LEDs
Bezel
Bezel
Platen
Platen
