Warning
Follow all installation instructions supplied by the pipe and fitting manufacturer.
The actual vent travel allowance is reduced for fittings as shown in the following tables:
Exhaust / Fittings EX 400, EX 500 EX 700, EX 850
4-inch rigid pipe 170 ft (max.) each side Not allowed
6-inch rigid pipe n/a 120 ft (max.) each side
90° vent elbow allow 5 ft for each elbow
45° elbow allow 3 ft for each elbow
PPs 87-90° elbows allow 5 ft for each elbow
Table 4 Maximum Exhaust Venting Length for EX 400, 500, 700, and 850 models
For example, for an EX 850 using 6 x 90º CPVC vent elbows, the maximum lineal measure
of pipe allowed is 90 feet (120' – (6 x 5' = 30) = 90').
Note
Unused intake travel cannot be added to the exhaust. Unequal intake and exhaust piping
is allowed.
Exhaust venting must slope down towards the boiler with a
pitch of at least 1/4" per foot (PP vent: follow PP
manufacturer requirements for slope), so condensate runs
back towards the trap. Support should be provided for
intake and vent piping, particularly for horizontal runs (follow
local code
