7.2 Replacing the fan, gas valve, and burner in EX 400
and EX 500 models
This section documents the following maintenance procedures for EX 400 and EX 500 models:
Replacing the fan
Replacing the gas valve
Replacing the burner.
Fan
Shutoff valve
Manifold gas pressure test port
Inlet gas pressure test port
High pressure switch
Low pressure switch
