IBC SL 14-115 G3 - Cabinet Dimensions

Boiler Specification SL 10-85 G3 SL 14-115 G3 SL20-160 G3 SL 30-199 G3
Limit
Max. ΔT - supply/return (electronic
fence)
40°F 40°F 40°F 40°F
Maximum equivalent vent length ,
each side (vent & air intake)
(Natural gas or propane)
Air intake options: either direct vent
or indoor supply
100’ (2")
240’ (3")
100’ (2")
240’ (3")
35’ (2")
170’ (3")
Not applicable
150’ (3")
* Boilers are shipped with a 30 psig pressure relief valve.
Cabinet dimensions
SL 10-85 G3, SL14-115 G3
Figure 1 : Front and side view - SL 10-85 G3, SL14-115 G3
6
Section: Specifications
