Page #69 background image
Gas valve inlet
Inlet gas pressure test port
Manifold gas pressure test port
Low fire adjustment (offset pressure)
Gas valve outlet
Orifice
O-ring
Gas valve outlet pipe
Fan inlet
Fan plug
Fan
65
6.3.3 Adjusting the gas valve
