Gas valve inlet
Inlet gas pressure test port
Manifold gas pressure test port
Low fire adjustment (offset pressure)- Do not adjust in the field
Gas valve outlet
Orifice
O-ring
Gas valve outlet tube
Fan inlet
77
7.3 Replacing the fan, gas valve, and burner
