14. Complete a mode 1 connection of one enclosure (A) by using a Y012 cable (B) to a single FC EJ0J or
FC EJ0M SAS adapter (C), as shown in Figure 14, then continue with “Connecting cables, power
cords, and installing covers” on page 22.
Note: The single FC EJ0J or FC EJ0M SAS adapter (C) has access to all 12 or 24 drive bays.
15. Complete a mode 1 connection of two enclosures (A and B) by using YO12 cables (C and D) to a
single FC EJ0J or FC EJ0M SAS adapter (E), as shown in Figure 15 on page 16, and then continue
with “Connecting cables, power cords, and installing covers” on page 22.
Note: The single SAS adapter (E) has access to all 24 or 48 drive bays.
Figure 14. Mode 1 connection of one ESLL or ESLS storage enclosure by using a YO12 cable to a single FC EJ0J or
FC EJ0M SAS adapter
Installing the Model 024, ESLL, or ESLS storage enclosure 15
