7. Using a multimeter, measure for the appropriate voltages between phases. If no voltage is present on
the receptacle case or grounded pin, the receptacle is safe to touch.
8. Using a multimeter, verify that the voltage at the AC outlet is correct.
Results
Power distribution unit and Intelligent Switched High Function PDU
The power distribution unit (PDU), power distribution unit plus (PDU+) or Intelligent Switched High
Function PDU can be installed in the 7014-T00 and 7014-T42 racks. It allows you to monitor the
individual power loads of the devices that are plugged into it.
Installing the PDU, PDU+, Intelligent Switched PDU, or Intelligent Switched PDU+ in the side of a rack
Learn how to install the power distribution unit (PDU), power distribution unit plus (PDU+), Intelligent
Switched PDU, or Intelligent Switched PDU+ vertically in the side of a rack.
Before you begin
Tip: Removing the rack doors and side panels makes installing the PDU easier.
About this task
To install the PDU model in a single EIA vertical mounting space in the side of the rack, complete the
following steps:
Procedure
1. Read the “Rack safety notices” on page 1
.
2. Choose one of the following options to install your PDU model:
• To install the PDU, Intelligent Switched PDU, or Intelligent Switched PDU+, go to step “5” on page
54.
• To install the PDU+, continue with step “3” on page 53.
3. Align the vertical-mounting brackets (A) to the front of the PDU+.
Make sure that you attach the brackets so that the power outlets face the rear of the rack.
