IBM BladeCenter HX5 15
Processor options
The HX5 supports the processor options listed in the following tables. The server supports one or two
processors. It is supported to have one processor in a single-node + MAX5 configuration. It is also
supported to have one processor in each node of a two-node system. You will, however, get better
memory performance if both processor sockets are populated in each HX5.
Note that not all processors can scale to two nodes. These are indicated in the tables. In addition, the
E7-2820 and the E7-2803 also do not support the attachment of the MAX5. This is a technical restriction
of these specific processors.
Table 8. Processor options for machine type 7873 (Intel Xeon E7 series processors)
Part number Feature code Intel Xeon processor description Can scale
to 2-node
Models
where used
88Y6124 A176 / A17P Xeon E7-8867L 10C 2.13 GHz 30 MB 1066 MHz
105w
Yes D1x
88Y6112 A174 / A17M Xeon E7-8837 8C 2.67 GHz 24 MB 1066 MHz
130w
Yes C1x
88Y6160 A18S / A18W Xeon E7-4870 10C 2.40 GHz 30 MB 1066 MHz
130w
Yes F2x, F5x, FEx,
FNx
88Y6102 A172 / A17K Xeon E7-4860 10C 2.26 GHz 24 MB 106 6MHz
130w
Yes -
88Y6092 A170 / A17H Xeon E7-4850 10C 2.00 GHz 24 MB 1066 MHz
130w
Yes -
88Y6082 A16Z / A17G Xeon E7-4830 8C 2.13 GHz 24 MB 1066 MHz
105w
Yes B2x, F1x, G2x,
F4x, FDx, FMx
88Y6076 A16Y / A17F Xeon E7-4820 8C 2.00 GHz 18 MB 978 MHz 105w Yes -
88Y6070 A16X / A17E Xeon E7-4807 6C 1.86 GHz 18 MB 800 MHz 95w Yes B1x, F3x, F6x
88Y6150 A18Q / A18U Xeon E7-2870 10C 2.40 GHz 30 MB 1066 MHz
130w
No A3x
69Y3094 A16V / A17C Xeon E7-2860 10C 2.26 GHz 24 MB 1066 MHz
130w
No A2x
69Y3084 A16T / A17A Xeon E7-2850 10C 2.00 GHz 24 MB 1066 MHz
130w
No -
69Y3074 A16S / A179 Xeon E7-2830 8C 2.13 GHz 24 MB 1066 MHz
105w
No A1x
69Y3068 A16R / A178 Xeon E7-2820 8C 2.00 GHz 18 MB 978 MHz 105w No* -
69Y3062 A16Q / A177 Xeon E7-2803 6C 1.73 GHz 18 MB 800 MHz 105w No* -
* The E7-2820 and the E7-2803 also do not support the attachment of the MAX5
