IBM BladeCenter HX5 Product Guide

IBM BladeCenter HX5 16
Memory options
IBM DDR3 memory is compatibility tested and tuned for optimal System x performance and throughput.
IBM memory specifications are integrated into the light path diagnostics for immediate system
performance feedback and optimum system uptime. From a service and support standpoint, IBM memory
automatically assumes the IBM system warranty, and IBM provides service and support worldwide.
The BladeCenter HX5 and the MAX5 memory expansion blade support DDR3 memory. The server has 16
DIMM sockets and the MAX5 has 24 DIMM sockets. When only one processor is installed, only eight of
the 16 DIMM sockets in the server are active (all sockets in the MAX5 are active, however).
The following tables lists memory options available for the HX5 server and for the MAX5 memory
expansion unit. Memory must be installed in pairs of two identical DIMMs per processors installed.
Although the DIMM pairs installed can be of different sizes, the pairs must be of the same speed.
Table 9. Memory options for machine type 7873 (Intel Xeon E7 series processors)
Part
number
Feature
code
Description Supported
in HX5 and
MAX5 V2
Maximum
supported*
Models where
used
46C0560 A0WX 2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
Yes 16 / 40 -
46C0564 A0WZ 4GB (1x4GB, 2Rx8, 1.35V) PC3L-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
Yes 16 / 40 All other models
00D4985 A3BU 8GB (1x8GB, 2Rx8, 1.35V) PC3L-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
Yes 16 / 40 -
46C0570 A17Q 8GB (1x8GB, 4Rx8, 1.35V) PC3L-8500
CL7 ECC DDR3 1066MHz VLP RDIMM
Yes 16 / 40 A4x, A5x, A6x, B3U, G1x,
G2x, G3x, G4x, E1x, E2x,
E3x, E4x, 91x, 92x, 93x, 94x
46C0599 2422 16GB (1x16GB, 2Rx4, 1.35V) PC3L-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
Yes 16 / 40 A6x, A7x
90Y3221 A2QP 16GB (1x16GB, 4Rx4, 1.35V) PC3L-8500
CL7 ECC DDR3 1066MHz VLP RDIMM
Yes 16 / 40 -
00D5008 A3KN 32GB (1x32GB, 4Rx4, 1.35V) PC3L-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
Yes 16 / 40 -
44T1596 1908 4GB (1x4GB, 2Rx8, 1.5V) PC3-10600
CL9 ECC DDR3 1333MHz VLP RDIMM
MAX5 V1
only**
24
(MAX5 only)
-
46C7499 1917 8GB (1x8GB, 4Rx8, 1.5V) PC3-8500
CL7 ECC DDR3 1066MHz VLP RDIMM
MAX5 V1
only**
24
(MAX5 only)
-
* 16 DIMMs can be installed in the HX5 server. With a MAX5 attached the total number of installable DIMMs is 40.
** These DIMMs are not supported in the HX5 or MAX5 V2, but are supported in the MAX5 V1, 46M6973
The following memory protection technologies are supported:
ECC

ChipKill

Memory Mirroring

Memory Sparing

Redundant Bit Steering (MAX5 or servers with E7 processors only, x4 DIMMs only)

