Chapter 2. Architecture and technical overview 49
For the PS701, Table 2-5 shows the required placement of memory DIMMs depending on the
number of DIMMs installed.
Table 2-5 PS701 DIMM placement rules
DIMM socket: PS701
Number of DIMMs to install:
2 4 6 8 10 12 14 16
P1-C1
x x x x x x x x
P1-C2
x x x x
P1-C3
x x x x x x x x
P1-C4
x x x x
P1-C5
x x x
P1-C6
x x x x x x
P1-C7
x x x
P1-C8
x x x x x x
P1-C9
x x x x x
P1-C10
x
P1-C11
x x x x x
P1-C12
x
P1-C13
x x
P1-C14
x x x x x x x
P1-C15
x x
P1-C16
x x x x x x x
