54 IBM BladeCenter PS700, PS701, and PS702 Technical Overview and Introduction
Figure 2-9 shows the locations of the PCIe CIOv and CFFh connectors and the physical
location codes for the PS700.
Figure 2-9 PS700 location codes for PCIe expansion cards
Figure 2-10 shows the locations of the PCIe CIOv and CFFh connectors for the PS701 and
PS702 base planar and the physical location codes. The expansion unit for the PS702 uses
the prefix P2 for the slots on the second planar.
Figure 2-10 PS701 and PS702 base location codes for PCIe expansion cards
CFFh connector - P1-C12 CIOv connector - P1-C11
CFFh connector - P1-C20 CIOv connector - P1-C19
