Introduction 13
Features, specifications, and standards
1
• VLAN filtering and tagging
A mechanism that allows multiple networks to transparently share the same physical network
link without leakage of information between networks. Switches are configured to insert an
appropriate VLAN tag into all data frames arriving from devices in a given VLAN. After the
frames are switched, the VLAN tag is stripped before the frame is sent back to the devices. In
this way, traffic from devices in one VLAN cannot be leaked to another VLAN.
• VMware NetQueue
Improves performance in 10 GbE virtualized environments. Requires MSI-X support on host
system.
Adapter specifications
Table 2 contains additional specifications for the adapter.
TABLE 2 Additional adapter specifications
Feature Description
Port speeds 10.312 Gbps
ASIC
• Provides the FCoE functionality for the Brocade 2-Port 10GbE Converged
Network Adapter.
• Two on-board processors, each operating at 400 MHz, which coordinate
and process data in both directions.
External serial
FLASH memory
• Stores firmware and adapter BIOS code
• 4 MB capacity
Data transfer rate 10.312 Gbps full-duplex
Performance per
port
500,000 IOPs (maximum)
Power dissipation 10 W maximum
Dimensions 4.9 in. by 0.5 in. by 6.3 in. (12.44 cm by 1.27 cm by 16 cm)
