4
f2c02313
Frame
8
11
9
12
10
8
7
6
5
4
3
2
1
▌1▐ Yoke
▌2▐ Nut, left-hand thread
▌3▐ Turnbuckle ½-13 right hand and left hand
▌4▐ Nut
▌5▐ Washer
▌6▐ Bushing
▌7▐ Load plates
▌8▐ Bushing, Plastic
▌9▐ Rods, ½-13 right hand, 304 mm, or 533 mm
▌10▐ Spacer
▌11▐ Washer flat, thick
▌12▐ Washer flat, custom
Figure 22. Raised floor tie-down installation
150 DS8880 Introduction and Planning Guide
