5. If you have a CD-ROM audio cable, connect it to the drive and to the system
board. See “Identifying parts on the system board” on page 63.
Connecting an additional IDE CD drive or DVD drive
1. Locate the secondary IDE connector on the system board and the
three-connector signal cable. See “Identifying parts on the system board” on
page 63.
2. Connect the extra connector in the signal cable to the new CD drive or DVD
drive.
3. Your computer has extra power connectors for additional drives. Connect a
power connector to the drive.
Connecting an additional IDE hard disk drive
1. Locate the primary IDE connector on the system board. One end of the
three-connector cable connects to the hard disk drive, and the other connects to
the system board. See “Identifying parts on the system board” on page 63.
2. Connect the extra connector in the signal cable to the new hard disk drive.
3. Your computer has extra power connectors for additional drives. Connect a
power connector to the drive.
What to do next
v To work with another option, go to the appropriate section.
v To complete the installation, go to “Replacing the cover and connecting the
cables” on page 74.
Installing a rope clip
To help prevent hardware theft, you can add a 3/16-inch or 5-mm rope clip and
cable to your computer. After you add the security cable, make sure that it does
not interfere with other cables that are connected to the computer. For more
information about security, see Installing a cable lock in Access IBM.
To install a rope clip:
1. Remove cover (see “Removing the cover” on page 61).
Chapter 4. Types 8307, 8308, 8310, 8311, 8314, and 8315 71
