Figure 2-10 through Figure 2-14 on page 59 show the various installation orders of the
DIMMs that use one, two, three or four memory riser cards.
Figure 2-10 Memory DIMM installation sequence for one processor with two riser cards
Pair 2
Pair 4
Pair 2
Pair 4
Pair 3
Pair 1
Pair 3
Pair 1
POWER7+
P1-C11
Memory Card #1  P1-C18
P1-C18-C1
P1-C18-C2
P1-C18-C3
P1-C18-C4
P1-C18-C7
P1-C18-C8
P1-C18-C9
P1-C18-C10

IBM Power 720 Specifications

General

Processor	POWER7
Operating System	AIX, IBM i, Linux
Memory Slots	16
Disk Bays	8
RAID Support	RAID 0, 5, 6, 10
Form Factor	4U rack
Processor Speed	3.0 GHz or 3.7 GHz
