68 IBM Power 720 and 740 Technical Overview and Introduction
2.7.4 Graphics accelerator adapters
Table 2-12 lists the available graphics accelerator adapters. They can be configured to
operate in either 8-bit or 24-bit color modes. These adapters support both analog and digital
monitors, and they are not hot-pluggable.
Table 2-12 Available graphics accelerator adapters
2.7.5 SCSI and SAS adapters
To connect to external SCSI or SAS devices, the adapters listed in Table 2-13 are available.
Table 2-13 Available SCSI and SAS adapters
Feature
code
CCIN Adapter description Slot Size OS support
5269 5269 PCIe LP POWER GXT145
Graphics Accelerator
PCIe Low profile,
short
AIX, Linux
5748 5748 POWER GXT145 PCI Express
Graphics Accelerator
PCIe Full height,
short
AIX, Linux
Feature
code
CCIN Adapter description Slot Size OS support
5278 57B3 PCIe LP 2-x4-port SAS adapter 3
Gb
PCIe Low profile,
short
AIX, IBM i,
Linux
5736 571A PCI-X DDR Dual Channel Ultra320
SCSI adapter
PCI-X Full height AIX, IBM i,
Linux
5805
b
574E PCIe 380 MB Cache Dual - x4 3 Gb
SAS RAID adapter
PCIe Full height,
short
AIX, IBM i,
Linux
5900
a
a. Supported, but no longer orderable.
572A PCI-X DDR Dual -x4 SAS adapter PCI-X Full height,
short
AIX, Linux
5901 57B3 PCIe Dual-x4 SAS adapter PCIe Full height,
short
AIX, IBM i,
Linux
5902 PCI-X DDR Dual - x4 3 Gb SAS
RAID adapter
PCI-X Full height AIX, Linux
5908 575C PCI-X DDR 1.5 GB Cache SAS
RAID adapter (BSC)
PCI-X Full height,
short
AIX, IBM i,
Linux
5912 572A PCI-X DDR Dual - x4 SAS adapter PCI-X Full height,
short
AIX, IBM i,
Linux
5913
b
b. A pair of adapters is required to provide mirrored write cache data and adapter redundancy.
57B5 PCIe2 1.8 GB Cache RAID SAS
adapter Tri-port 6 Gb
PCIe Full height,
short
AIX, IBM i,
Linux
ESA1 57B4 PCIe2 RAID SAS adapter Dual-port
6Gb
PCIe Full height AIX, IBM i,
Linux
ESA2 57B4 PCIe2 LP RAID SAS adapter
Dual-port 6 Gb
PCIe Low profile AIX, IBM i,
Linux
