Table 27. Bulk power assembly (BPA) locations and failing components (continued)
Failing item name Identify LED Physical location code
Connector J10, MDA 1 and 3, Y cable powers
2 MDAs
No Un-Px-C1–J10
Connector J11, MDA 2 and 4, Y cable powers
2 MDAs
No Un-Px-C1–J11
Bulk power distribution (BPD) connectors
BPD1 No Un-Px-C2
Connector J01, I/O drawer 1, DCA 2 No Un-Px-C2–J01
Connector J02, I/O drawer 1, DCA 1 No Un-Px-C2–J02
Connector J03, I/O drawer 2, DCA 2 No Un-Px-C2–J03
Connector J04, I/O drawer 2, DCA 1 No Un-Px-C2–J04
Connector J05, I/O drawer 3, DCA 2 No Un-Px-C2–J05
Connector J06, I/O drawer 3, DCA 1 No Un-Px-C2–J06
Connector J07, node P5 No Un-Px-C2–J07
Connector J08, node P9 No Un-Px-C2–J08
Connector J09, node P2 No Un-Px-C2–J09
Connector J10, node P6 No Un-Px-C2–J10
BPD2 No Un-Px-C3
Connector J01, I/O drawer 4, DCA 2 No Un-Px-C3–J01
Connector J02, I/O drawer 4, DCA 1 No Un-Px-C3–J02
Connector J03, I/O drawer 5, DCA 2 No Un-Px-C3–J03
Connector J04, I/O drawer 5, DCA 1 No Un-Px-C3–J04
Connector J05, I/O drawer 6, DCA 2 No Un-Px-C3–J05
Connector J06, I/O drawer 6, DCA 1 No Un-Px-C3–J06
Connector J07, node P4, or I/O drawer 7 No Un-Px-C3–J07
Connector J08, node P3, or I/O drawer 8 No Un-Px-C3–J08
Connector J09, node P8, or I/O drawer 9 No Un-Px-C3–J09
Connector J10, node P7, or I/O drawer 10 No Un-Px-C3–J10
Bulk power hub (BPH) No Un-Px-C4
Connector J01–J24 No Un-Px-C4–Jmm
UEPO panel Un-D1
Connector J01 to BPC-A Un-D1–J01
Connector J02 to BPC-B Un-D1–J02
Central electronics complex (CEC)
CEC cage No Un
System backplane Yes Un-P1
System VPD card Yes Un-P1–C1
FSP card 0 Yes Un-P1–C2
Clock card 0 Yes Un-P1–C3
Clock card 1 Yes Un-P1–C4
FSP card 1 Yes Un-P1–C5
Finding parts, locations, and addresses 91
