Table 27. Bulk power assembly (BPA) locations and failing components (continued)
Failing item name Identify LED Physical location code
Processor book 0, plugs into midplane Yes Un-P2
Processor book 1 Yes Un-P6
Processor book 2 Yes Un-P3
Processor book 3 Yes Un-P7
Processor book 4 Yes Un-P4
Processor book 5 Yes Un-P8
Processor book 6 Yes Un-P5
Processor book 7 Yes Un-P9
Air moving device AMD 1 Yes Un-A1
Motor drive assembly (MDA) 1 Yes Un-A1–E1
Air moving device AMD 2 Yes Un-A2
MDA 2 Yes Un-A2–E1
Air moving device AMD 3 Yes Un-A3
MDA 3 Yes Un-A3–E1
Air moving device AMD 4 Yes Un-A4
MDA 4 Yes Un-A4–E1
Processor book, where m is 2 – 9
Processor book Un-Pn
DCA 1 Yes Un-Pm-E2
DCA 2 Yes Un-Pm-E1
GX++ cards, where m is 2 – 9
Slot T Yes Un-Pm-C41
Slot S Yes Un-Pm-C44
Slot U Yes Un-Pm-C39
Slot V Yes Un-Pm-C40
GX++ card connectors, where m is 2 – 9
Slot T Yes Un-Pm-C41–T01 and Un-Pm-C41–T02
Slot S Yes Un-Pm-C44–T01 and Un-Pm-C44–T02
Slot U Yes Un-Pm-C39–T01 and Un-Pm-C39–T02
Slot V Yes Un-Pm-C40–T01 and Un-Pm-C40–T02
Book FSP card 1 Yes Un-Pm-C43
Book FSP card 0 Yes Un-Pm-C42
LED service card Yes Un-Pm-C01
TPMD card Yes Un-Pm-C30
FSP card connector J01 Yes Un-Pm-Cn-T01
FSP card connector J02 Yes Un-Pm-Cn-T02
Memory Where m varies from 2 – 9
DIMM V-M1-B Yes Un-Pm-C3
DIMM V-M1-C Yes Un-Pm-C4
DIMM V-M1-D Yes Un-Pm-C5
92 Finding parts, locations, and addresses
