IBM Power Systems 8202-E4B Site And Hardware Planning

Table 141. Supported SAS cables for PCIe2 and prior SAS adapters (continued)
Name Length IBM part number Feature code
HD SAS YO cable 1.5 m (4.9 ft) 74Y9036 3450
3 m (9.8 ft) 74Y9037 3451
6 m (19.6 ft) 74Y9038 3452
10 m (32.8 ft) 74Y9039 3453
15 m (49.2 ft) 74Y9040 3457
SAS AA cable 3 m (9.8 ft) 44V8231 3681
6 m (19.6 ft) 44V8230 3682
SAS YO cable 1.5 m (4.9 ft) 44V4157 3691
3 m (9.8 ft) 44V4158 3692
6 m (19.6 ft) 44V4159 3693
15 m (49.2 ft) 44V4160 3694
SAS YI cable 1.5 m (4.9 ft) 44V4161 3686
3 m (9.8 ft) 44V4162 3687
SAS X cable 3 m (9.8 ft) 44V4154 3661
6 m (19.6 ft) 44V4155 3662
15 m (49.2 ft) 44V4156 3663
Disk backplane to rear
bulkhead, cascading.
(internal cable)
42R5751 3668
Split disk backplane to rear
bulkhead (internal cable)
44V5252 3669
The following table contains specific information about each supported SAS cable feature with narrow
HD connectors for PCIe3 SAS adapters.
Table 142. Supported SAS cables for PCIe3 SAS adapters
Name Length IBM part number Feature code
HD SAS AA12 narrow
connector cable, SAS
adapter to SAS adapter
0.6 m (1.9 ft) 01AF505 ECE0
1.5 m (4.9 ft) 01AF506 ECE2
3 m (9.8 ft) 01AF507 ECE3
1
4.5 m (14.8 ft) AOC
2
78P4917 ECE4
HD SAS X12 narrow
connector cable, SAS
adapter to storage
enclosure
3 m (9.8 ft) 01AF504 ECDJ
4.5 m (14.8 ft) AOC
2
78P4918 ECDK
10 m (32.8 ft) AOC
2
78P4919 ECDL
HD SAS YO12 narrow
connector cable, two SAS
adapters to storage
enclosure
1.5 m (4.9 ft) 01AF502 ECDT
3 m (9.8 ft) 01AF503 ECDU
4.5 m (14.8 ft) AOC
2
78P4920 ECDV
10 m (32.8 ft) AOC
2
78P4921 ECDW
HD SAS 4x AT narrow
connector cable
0.6 m (1.9 ft) 00E6291 ECBB
Site and hardware planning 125
