IBM Power Systems 8202-E4B Site And Hardware Planning

Feature code 0230 and 7886
Table 39. 550 in a rack
IBM rack Rack, specify code PDU support Power cords
7014
1
0230 and 7886 0 to 4
2
PDU
3
1
7014-T00 is a 1.8 meter rack with 36 EIA units of total space. 7014-T42 is a 2.0 meter rack with 42 EIA units of total
space. The rack includes one PDU, feature code 9188, 9176, 9177, or 9178.
2
0551, 0553, and 0555 feature codes 5160, 5161, 5163, and 7188. 7014 feature codes 7176, 7177, 7178, and 7188.
3
If unit plugs into a PDU, two feature code 6458, 6459, 6095, or 9911 power jumper cords are required.
Feature codes 0231, 0232, 0241, and 0242
Figure 6. 550 in a rack
Figure 7. 570 in rack
Site and hardware planning 23
