FRU P/N CRU
ID
System miscellaneous parts for 2887, 2888:
v (a) Cable, RJ11-docking connector on
system board
v (b) Antenna cable guide
v (c) EMI spring, CDC
v (e) DC in cable
v (f) Bracket, cable hook
v HDD connector retainer-CR
v (g) Bracket, VGA connector 14
v (g) Bracket, VGA connector 15
v (h) Bracket structure 14/15
v (i) Bracket, I/O plate 14/15-CR
v Connector bag
v Blank cap, IEEE1394 connector
v Spacer, IEEE1394 connector-CR
v (j) Retainer, LCD cable 14/15-CR
v Bracket M7 14-CR
v Bracket M7 15
v Ferrite core, LH
v Bracket, joint 14-CR
v Bracket, joint 15-CR
v Cu tape, VGA cable
Note:
Italicized letters in parentheses are
references to the exploded view on page 189.
13R2694 N
Parts list
268 R50/R50p, R51 Series
