IBM System x3750 M4 Product Guide

IBM System x3750 M4 14
Controllers for internal storage
The following table lists the RAID controllers and SAS HBAs used for the internal disk storage of the
x3750 M4 server.
Table 7. RAID controllers for internal storage
Part number Feature
code
Description Maximum
supported
Models
where used
Integrated A2N2 ServeRAID M5110e SAS/SATA Controller 1 (integrated) All
81Y4481
A347
ServeRAID M5110 SAS/SATA Controller 3 D1x (1 standard)
D2x (3 standard)
81Y4448
A1MZ
ServeRAID M1115 SAS/SATA Controller 1 -
46M0912 3876 IBM 6Gb Performance Optimized HBA 3 -
46C8988 A3MW N2115 SAS/SATA HBA for IBM System x 3 -
The integrated ServeRAID M5110e SAS/SATA Controller is a chip on the system board. The ServeRAID
M5110 is a PCIe low-profile, half-length (MD2) form factor adapter. Both controllers have the following
specifications:
Two Mini-SAS internal connectors.

6 Gbps throughput per port.

PCIe x8 2.0 host interface.

Based on the LSI SAS2208 6 Gbps ROC controller.

Supports RAID levels 0, 1, and 10.

Supports RAID levels 5 and 50 with optional M5100 Series RAID 5 upgrades (see below).

Supports RAID 6 and 60 with the optional M5100 Series RAID 6 Upgrade (see below).

Supports 512 MB battery-backed cache or 512 MB or 1 GB flash-backed cache (see below).

The ServeRAID M1115 offers a low-cost RAID 0/1/10 solution that can be upgraded to a cacheless RAID
5 with a Features-on-Demand license upgrade. It has the following specifications:
PCI Low Profile, Half-length - MD2 form factor

Two internal Mini-SAS connectors (SFF-8087)

Eight internal 6 Gbps SAS/SATA ports

6 Gbps throughput per port

533 MHz IBM PowerPC® processor with LSI SAS2008 6 Gbps RAID on Chip (ROC) controller

PCI Express 2.0 x8 host interface

Support for RAID levels 0, 1, and 10 standard; support for RAID 5 and 50 with an optional upgrade

(81Y4542)
Zero Controller Cache, no battery/flash backup

For more information, see the list of IBM Redbooks Product Guides in the RAID adapters category:
http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=raid
Note: The supported adapters for internal storage need to be installed in slots 1, 2 and 3 because of cable
routing requirements. The IBM x3750 M4 PCIe 3x8 riser (88Y7371) must be installed. These slots also
require that Processor 2 be installed.
