IBM System x3750 M4 23
PCIe SSD adapters
The server supports the High IOPS SSD adapters listed in the following table.
Note: The server supports a maximum quantity of three of the full-height adapters, which must be
installed in slots 1, 2, and 3. These slots require the second processor and the 3-slot riser card, 88Y7371.
Table 14. SSD adapters
Part number Feature
code
Description Maximum
supported
46M0877 0096 IBM 160GB High IOPS SS Class SSD PCIe Adapter 8
46M0878 0097 IBM 320GB High IOPS SD Class SSD PCIe Adapter 3
46M0898 1649 IBM 320GB High IOPS MS Class SSD PCIe Adapter 8
81Y4539 A1ND 640GB High IOPS SLC Duo Adapter For IBM System x 3
81Y4535 A1NE 320GB High IOPS SLC Adapter For IBM System x 8
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 7
90Y4397 A3DZ IBM 2.4TB High IOPS MLC Duo Adapter 3
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 7
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 7
90Y4361* A3MZ IBM 300GB High IOPS MLC Modular Adapter 3
90Y4365* A3N0 IBM 600GB High IOPS MLC Modular Adapter 3
90Y4369* A3N1 IBM 800GB High IOPS MLC Modular Adapter 3
90Y4373* A3N2 IBM 300GB High IOPS SLC Modular Adapter 3
* These modular adapters are not available via CTO or Special build. The adapter cannot be shipped installed and
instead must be shipped in its option box and configured at the final installation location. For more information, see
https://ibm.com/support/entry/myportal/docdisplay?lndocid=SERV-IOMA
For details about these adapters, see the IBM Redbooks Product Guide
IBM High IOPS SSD PCIe
Adapters
, found at the following address:
http://www.redbooks.ibm.com/abstracts/tips0729.html?Open
