FRU REMOVALS AND REPLACEMENTS
2010 LCD Front Cover
Battery pack (1030)
Hard disk drive (1040)
UltraslimBay device (1050)
Keyboard assembly (1060)
LCD assembly (1090)
Important
The TFT LCD for the notebook computer contains
over 2,359,296 thin-film transistors (TFTs). A small
number of dots that are missing, discolored, or always
lighted is characteristic of TFT LCD technology, but
excessive pixel problems can cause viewing concerns.
The LCD should be replaced if the number of missing,
discolored, or lighted dots in any background is:
XGA (13.3 in.): 5 or more bright dots, 5 or more
dark dots, or a total of 9 or more bright and dark
dots.
Step Screw (Quantity) Color Torque
.1/ M2.5 × 4.8 mm,
nylon-coated (2)
Black 4 kgcm
.1/ M2.5 × 4.8 mm,
nylon-coated (4)
Black 4 kgcm
60 ThinkPad 600X Hardware Maintenence Manual
