IBM ThinkPad T43 Hardware Maintenance Manual

3
3
4
When installing:
1. Plug the gray cable to jack M, and the black cable to
jack A.
2. Insert the notched end of the card into the socket, and
then press the card firmly. Pivot the card until it snaps
into place. Make sure that it is firmly fixed in the slot
and does not move easily.
Removing and replacing a FRU
100 MT 2668/2669/2686/2687

IBM ThinkPad T43 Specifications

General

RAM	512MB (upgradable to 2GB)
Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Operating System	Windows XP Professional
Wireless	Intel PRO/Wireless 2200BG or 2915ABG
Modem	56K V.92
Processor	Intel Pentium M
Storage	40GB HDD
Display	14.1 inch
Graphics	ATI Mobility Radeon X300 or Intel GMA 900
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo, or DVD±RW
Battery	6-cell or 9-cell Lithium-Ion
Chipset	Intel 915PM
Ethernet	Gigabit Ethernet
Ports	1 x VGA, 1 x Headphone, 1 x Microphone
Networking	Bluetooth (optional)
