IBM ThinkPad T43 - 2060 Wireless Antenna Assemblies, LCD Panel, LCD Cable Assembly, Hinges, and LCD Cover (15.0-In. LCD Models)

2060 Wireless antenna assemblies, LCD
panel, LCD cable assembly, hinges, and
LCD cover (15.0-in. LCD models)
For access, remove these FRUs in order:
v “1020 Battery pack (15.0-in. LCD models)” on page 74
v “1040 Hard disk drive” on page 76
v “1060 Keyboard” on page 80
v “1090 Bluetooth/Modem daughter card (BMDC-3)” on
page 88
v “1110 Keyboard bezel or Keyboard bezel with fingerprint
reader (15.0-in. LCD models)” on page 93
v “1120 Mini PCI adapter” on page 99
v “1200 LCD assembly (15.0-in. LCD models)” on page
120
v “2020 LCD front bezel (15.0-in. LCD models)” on page
150
v “2040 Inverter card (15.0-in. LCD models)” on page 154
1
1
1
1
1
1
Step Screw (quantity) Color Torque
1 M2 × 4 mm, bind-head,
nylon-coated (7)
Black 0.245 Nm
(2.5
kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T43/T43p Series 169
