IBM ThinkPad T43 Hardware Maintenance Manual

1100 Palm rest or Palm rest with
fingerprint reader (14.1-in. LCD models)
For access, remove these FRUs in order:
v “1010 Battery pack (14.1-in. LCD models)” on page 72
v “1040 Hard disk drive” on page 76
v “1060 Keyboard” on page 80
Notes
v In models with the fingerprint reader, the sensor
has been attached to the palm rest FRU as the
child part. In case of the fingerprint reader has
any defects and needs to be replaced, you need
to replace the palm rest by following the
procedures in this section. The procedures are
same both for the palm rest without the fingerprint
reader and for the palm rest with the fingerprint
reader.
v For some models, this FRU is secured by using a
tamper resistant torx head screw (TR7).
(continued)
Removing and replacing a FRU
90 MT 2668/2669/2686/2687

IBM ThinkPad T43 Specifications

General

RAM	512MB (upgradable to 2GB)
Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Operating System	Windows XP Professional
Wireless	Intel PRO/Wireless 2200BG or 2915ABG
Modem	56K V.92
Processor	Intel Pentium M
Storage	40GB HDD
Display	14.1 inch
Graphics	ATI Mobility Radeon X300 or Intel GMA 900
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo, or DVD±RW
Battery	6-cell or 9-cell Lithium-Ion
Chipset	Intel 915PM
Ethernet	Gigabit Ethernet
Ports	1 x VGA, 1 x Headphone, 1 x Microphone
Networking	Bluetooth (optional)
