IBM ThinkPad T43 Hardware Maintenance Manual

3
4
2
Step Screw (quantity) Color Torque
2 M2 × 14 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5
kgfcm)
After removing the screw, remove bracket 3. Then
detach the LCD connector 4.
When installing: Make sure that the bracket 3 and the
connector 4 are firmly attached, and
then secure them with the screw.
(continued)
Removing and replacing a FRU
116 MT 2668/2669/2686/2687

IBM ThinkPad T43 Specifications

General

RAM	512MB (upgradable to 2GB)
Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Operating System	Windows XP Professional
Wireless	Intel PRO/Wireless 2200BG or 2915ABG
Modem	56K V.92
Processor	Intel Pentium M
Storage	40GB HDD
Display	14.1 inch
Graphics	ATI Mobility Radeon X300 or Intel GMA 900
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo, or DVD±RW
Battery	6-cell or 9-cell Lithium-Ion
Chipset	Intel 915PM
Ethernet	Gigabit Ethernet
Ports	1 x VGA, 1 x Headphone, 1 x Microphone
Networking	Bluetooth (optional)
