IBM ThinkPad T43 Hardware Maintenance Manual

Feature Description
Optional memory v 256-MB DDR2-533 SDRAM SO-DIMM
(PC2-4200) card × 1
v 512-MB DDR2-533 SDRAM SO-DIMM
(PC2-4200) card × 1
v 1-GB DDR2-533 SDRAM SO-DIMM
(PC2-4200) card × 1
(maximum
of 2048 MB)
CMOS RAM v 242 bytes
Hard disk drive v 30.0 GB, 4200 rpm, 9.5 mm high, IDE
interface
v 40.0 GB, 4200 rpm, 9.5 mm high, IDE
interface
v 40.0 GB, 5400 rpm, 9.5 mm high, IDE
interface
v 60.0 GB, 5400 rpm, 9.5 mm high, IDE
interface
v 80.0 GB, 5400 rpm, 9.5 mm high, IDE
interface
v 60.0 GB, 7200 rpm, 9.5 mm high, IDE
interface
Supported
hard disk drives are depend on
the model.
Ultrabay Slim device
(standard)
v DVD drive, 9.5 mm high
v DVD/CD-RW combo drive, 9.5 mm high
v DVD-RAM/RW drive, 9.5 mm high
Fingerprint reader Some models
I/O port v External monitor connector
v Stereo headphone jack
v Monaural microphone jack
v Infrared port
v Parallel connector
v Docking connector
v RJ11 connector
v RJ45 connector
v TV-out connector (S-Video)
v Universal serial bus (USB) connector × 2
(compatible with USB 1.1 and 2.0)
Internal modem v 56.6 Kbps
Audio v Built-in stereo speakers
v Software control volume
Infrared transfer v IrDA 1.1
Ethernet (on the
system board)
v Gigabit Ethernet
(continued)
Product overview
48 MT 2668/2669/2686/2687

IBM ThinkPad T43 Specifications

General

RAM	512MB (upgradable to 2GB)
Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Operating System	Windows XP Professional
Wireless	Intel PRO/Wireless 2200BG or 2915ABG
Modem	56K V.92
Processor	Intel Pentium M
Storage	40GB HDD
Display	14.1 inch
Graphics	ATI Mobility Radeon X300 or Intel GMA 900
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo, or DVD±RW
Battery	6-cell or 9-cell Lithium-Ion
Chipset	Intel 915PM
Ethernet	Gigabit Ethernet
Ports	1 x VGA, 1 x Headphone, 1 x Microphone
Networking	Bluetooth (optional)
