1U
1U
Rack Mounting
Template
BACK
1U
Screws required to secure rails
before installing chassis
1U
Note: If the rack rail has round
holes, install the M5 clip nuts
from the installation kit.
M5
clip
nut
Optional
shipping
bracket
screws
Optional
shipping
screws
bracket
Optional
shipping
screw
bracket
Optional
shipping
screw
bracket
Optional
shipping
screw
bracket
Optional
shipping
screw
bracket
3. Install the M5 cage nuts (for square holes) or M5 clip nuts (for round holes)
from the shipping bracket kit in the holes that are indicated on the template, if
shipping the server in a pre-installed rack.
Chapter 3. Rack installation 7
