IBO PC-59 - Application of the Device; Technical Data

Installation
20
Environmental requirements
Application
The PC-59 controller is an electronic device that controls the operation of the pump. The
device controls the operation of the pump by testing changes in water pressure in the
pipeline and water ow through the pipeline.
Thanks to the possibility of adjusting the pressure on and o by the user, the device fully
replaces traditional pressure switches and protects against dry running (operation of the
pump without water).
An integrated check valve prevents the system from returning water to the pump. The
pressure gauge with marked activation and deactivation levels enables precise and simple
adjustment of the device to the user’s needs. The device can work with or without a hy-
drophore tank.
Technical Data
External conditions have a direct eect on the operation and reliability of the device.
Therefore, the following conditions must be met:
- Permissible ambient temperature range: 0 ° C to + 40 ° C
- Indoor use only
- Install away from corrosive substances and explosive gases
- Install away from ammable materials
- Install in a dry and well-ventilated place
- Install in places beyond the range of electromagnetic interference
- Avoid dusty places or exposed to metal lings that can get into the controller
ATTENTION
• Power supply: 230 V
• Power frequency: 50 Hz
• Max power of the controlled pump :1,1 kW
• Max current consumption of the controlled pump: 10 A
• Max working pressure :10 bar
• Maximum ambient temperature: 40°C
• Degree of protection: IP65
• Pressure range: 1,5 bar
• Inlet / outlet: 1” / 1”
