Installation
22
Electrical Connection
Manual and Operation
- Cable connection must be performed by a specialist
- Work with cables must be carried out with the power supply switched o
-
Make sure the cables are connected properly and check the mains voltage before applying
power
- Please do not run the driver puncture test
- Make sure the earth clamp is connected
The device must be connected to an earthed network. After unscrewing the outer casing,
the grounding wire should be connected to the panel marked with the symbol
The ground wire of the pump cable must also be connected there.
Check before turning on the power
• Check that the input power and conditions match the nameplate data
•
Check if the controller is securely installed (permanently attached to the carrier,
carrier of sucient strength, temperature and humidity within the acceptable limits
COMMISSIONING, OPERATION:
There are two signaling lamps on the housing of the device. Red (or Green depen-
ding on mode 1 or 2) „Mode”, and yellow „Status”. After ooding the pump and the
suction pipe with water, and opening the uppermost tap, you can start to start the
pump. Commissioning takes place after connecting the electric power supply. Correct
connection of the power supply is indicated by the red „Mode” lamp.
If the pump starts to work, the yellow „Status” diode will also light up. As soon as water
starts owing from the highest located tap, it can be turned o. In this case, the PC59
will turn o power supply to the pump. The Status light goes out. Re-opening the tap
will automatically restart the pump and the „Status” light will be yellow. If water does
not start to ow from the tap, after the pump has stopped, hold down the „Fuction”
button until water appears in the tap.
