IBRAMED SONOPULSE III - Accessories Used; Ultrasound Transducer and Gel

31
ACCESSORIES USED
Figure 5. A, Ultrasound transducer with ERA of 7 cm
2
;
B, neutral conductor gel.
1 and 3 MHz ULTRASOUND: Ultrasound transducer with ERA of 7 cm
2
for frequency of 1 and 3 MHz, with neutral conductor
gel. (Figure 5).
A B
A B
The screws of the transducer connector must be rmly
xed to the device.
