IBRAMED SONOPULSE III - Glossaries; Abbreviations and Figures Glossaries

5
ABBREVIATIONS GLOSSARY
MHz
ERA
W
W/cm
2
cm
2
VA
BNR
Min
Megahertz (million pulses (10
6
) by second)
Eective Radiating Area
Watt (s)
Watt (s) per square centimeter
Square centimeter
Volt Ampere
Beam Non-Uniformity Ratio
Minute
FIGURES GLOSSARY
Figure 1. Upper view................................................26
Figure 2. Rear view..................................................26
Figure 3. Frontal view...............................................27
Figure 4. Lower view.................................................27
Figure 5. A, Ultrasound transducer with ERA of 7 cm
2
; B,
neutral conductor gel..................................................31
Figure 6. A, presentation message; B, standard/default
SONOPULSE III screen..............................................32
Figure 7. Application technique.................................38
Figure 8. A, slot for combined therapy of SONOPULSE III;
B, connector cable for combined therapy..........................40
Figure 9. Application technique for combined therapy.......41
Figure 10. Message of selection of language.................42
Figure 11. Programmed and User protocols display.........43
