CLINICAL RESOURCES LIBRARY - CLINICAL PROTOCOLS
* Intensity calculated according to the depth of the target tissue.
**The treatment time depends of the size of the treatment area and the ERA (Eective Radiating Area) of the transducer. The
operator must calculate the treatment time according to the size value of the treatment area divided by the value of the ERA of
the transducer.
Protocol 5 - 1 MHz
Rhomboid Injury
Acute Phase
Parameters values
Frequência 1 MHz
Mode Pulsed
Duty cycle 20 %
Pulse frequency 100 Hz
Intensity 1.5 W/cm²
Treatment time 1-30 min*
Protocol 6 - 3 MHz
Radiocarpal Extensor
Injury-Acute Phase
Parameters values
Frequency 3 MHz
Mode Pulsed
Duty cycle 20 %
Pulse frequency 100 Hz
Intensity 0.8 W/cm²
Treatment time 1-30 min*
