IBRAMED SONOPULSE III - Page 63

63
CLINICAL RESOURCES LIBRARY - CLINICAL PROTOCOLS
* Intensity calculated according to the depth of the target tissue.
**The treatment time depends of the size of the treatment area and the ERA (Eective Radiating Area) of the transducer. The
operator must calculate the treatment time according to the size value of the treatment area divided by the value of the ERA of
the transducer.
Protocol 39 - 3 MHz
Elbow Joint Stiness Parameters values
Frequency 3 MHz
Mode Continuous
Intensity 0.6 W/cm²
Treatment time 1-30 min*
Protocol 40 - 3 MHz
Knee or Ankle Joint
Stiness
Parameters values
Frequency 3 MHz
Mode Continuous
Intensity 0.4 W/cm²
Treatment time 1-30 min*
