41
Control range
Power factor setting 0.80ind… 0.80cap
Reconnection time of the same step 5… 240s
Sensitivity 5… 600s/step
Connections
Type of terminal Removable / Plug-in
Cable cross section (min-max) 0.2÷2.5mm² (24÷12 AWG)
Tightening torque 0.8 Nm (7LBin)
Operating ambient conditions
Operating temperature -20… +60°C
Storage temperature -30… +80°C
Relative humidity <90%
Enclosure 5LSA 7LSA 8BSA 12BSA
Version Flush mount
Material
Thermoplastic
NORYL SE1 GNF2
Thermoplastic
LEXAN 3412R
Dimensions wxhxd 96x96x65mm 144x144x62mm
Panel cutout dimension 91x91mm 138.5x138.5mm
Degree of protection IP54
IP41
(IP51 with protection
cover)
Weight 440g 460g 740g 770g
Reference standards
IEC/EN 61010-1; IEC/EN 61000-6-2; ENV 50204; CISPR 11/EN 55011; 61000-3-3;
IEC/EN 60068-2-61; IEC/EN60068-2-27; IEC/EN60068-2-6; UL508; CSA C22.2 No14-95
Certification
cULus pending
