A08 - Overtemperature
Internal temperature value is higher than the set threshold (refer to P.27 of advanced
menu).
A09 - No-voltage release
Voltage failure duration is more than 8ms.
1.22 TECHNICAL CHARACTERISTICS
Auxiliary supply 5LSA 7LSA 8BSA 12BSA
Rated voltage Ue 380… 415VAC (other values on request)
Operating limit -15%… +10% Ue
Rated frequency 50 o 60Hz ±1% (self configurable)
Maximum consumption 6.2VA
5VA
Maximum dissipation 2.7W 3W
Maximum power dissipated by output contacts 0.5W with 5A
Immunity time for micro-breaking =30ms
No-voltage release =8ms
Current input
Rated current Ie 5A (1A on request)
Operating limit 0.125… 6A
Constant overload +20%
Type of measurement True RMS
Short time withstand current 10Ie for 1s
Dynamic limit 20Ie for 10ms
Input power 0.65W
Output relay 5LSA 7LSA 8BSA 12BSA
Number of outputs
(1 output contact is galvanically isolated)
5 7 8 12
Type of output 4+1 N/O 6+1 N/O
7 N/O +
1 C/O
11 N/O +
1 C/O
Maximum current at contact common 12A
Rated capacity Ith 5A
Rated operating voltage 250VAC
Maximum switching voltage 400VAC
Designation according to
IEC/EN 60947-5-1 AC-DC
C/250, B/400
Electrical life at 0.33A, 250VAC
and AC11 load conditions
5x10
6
ops
Electrical life at 2A, 250VAC
and AC11 load conditions
4x10
5
ops
Electrical life at 2A, 400VAC
and AC11 load conditions
2x10
5
ops
