All dimensions are in inches
Use this table when an 18 inch adjustable length is required.
LENGTH
BETWEEN
15° Elbows
30° Elbows
45° Elbows
OFFSETS
RISE
OFFSET
RISE
OFFSET
RISE
OFFSET
5 inch Ø
6" Length
23 - 28 3/4
5 - 6 1/2
22 3/4 - 28
10--13
21 1/2 - 25 3/4
14 3/4 – 19
12" Length
28 3/4 - 34 1/2
6 1/2 - 8
28 - 33 1/4
13 - 16
25 3/4 -30
19 - 23 1/4
18" Length
34 1/2 - 40 1/4
8 - 9 1/2
33 1/4 - 38 1/2
16 - 19
30 - 34 1/4
23 1/4 - 27 ½
24" Length
40 1/4 - 46 1/4
9 1/2 - 11
38 1/2 - 43 1/2
19 - 22
34 1/4 - 38 1/2
27 1/2 - 31 3/4
48" Length
63 1/2 - 69 1/4
15 3/4 - 17 1/4
59 1/4 - 64 1/2
31 - 34
51 1/4 - 55 1/4
44 1/2 - 48 3/4
24" + 12"
50 1/4 – 56
12 1/4 - 13 3/4
47 1/4 -52 1/2
24 - 27
41 1/2 - 45 3/4
34 1/4 - 39
48" + 12"
73 1/2 - 79 1/4
18 1/2 - 20
68 - 73 1/4
36 - 39
58 1/4 -62 1/2
51 3/4 - 56
48" + 18"
79 1/4 – 85
20 - 21 1/2
73 1/4 - 78 1/2
39 - 42
62 1/2 -66 3/4
56 - 60 1/4
48" + 24"
85 - 90 3/4
21 1/2 - 23
78 1/2 - 83 3/4
42 - 45
66 3/4 - 71
60 1/4 - 641/2
48" + 24" + 12"
95 -100 3/4
24 1/4 - 25 3/4
87 1/4 - 92 1/2
47 1/4 - 50 1/4
74 - 78 1/4
67 1/2 - 71 3/4
48" + 48"
108 1/4 -114
27 3/4 - 29 1/4
99 1/4 -104 1/2
54 - 57
83 3/4 - 88
77 1/4 - 81 1/2
6 inch Ø
6" Length
23 1/4 - 29
5 - 6 1/2
23 1/4 - 28 1/2
10--13
22 1/4 - 26 1/2
15 - 19 1/4
12" Length
29 - 34 3/4
6 1/2 - 8
28 1/2 - 33 3/4
13 - 16
26 1/2 - 30 1/2
19 1/4 - 23 1/2
18" Length
34 3/4 - 40 1/2
8 - 9 1/2
33 3/4 - 39
16 - 19
30 1/2 - 34 3/4
23 1/2 - 27 3/4
24" Length
40 1/2 - 46 1/2
9 1/2 - 11 1/4
39 - 44
19 - 22
34 3/4 - 39
27 3/4 - 32
48" Length
63 3/4 - 69 1/2
15 3/4 - 17 1/4
59 3/4 - 65
31 - 34
51 3/4 - 56
44 3/4 - 49
24" + 12"
50 1/2 - 56 1/4
12 1/4 - 13 3/4
47 3/4 - 53
24 1/4 - 27 1/4
42 - 46 1/4
35 - 39 1/4
48" + 12"
73 3/4 - 79 1/2
18 1/2 - 20
68 1/2 - 73 3/4
36 1/4 - 39 1/4
59 - 63 1/4
52 - 56 1/4
48" + 18"
79 1/2 - 85 1/4
20 - 21 1/2
73 3/4 - 79
39 1/4 - 42 1/4
63 1/4 - 67 1/2
56 1/4 - 60 1/2
48" + 24"
85 1/4 - 91
21 1/2 - 23
79 - 84 1/4
42 1/4 - 45 1/4
67 1/2 - 71 3/4
60 1/2 - 64 3/4
48" + 24" + 12"
95 1/4 - 101
24 1/4 - 25 3/4
87 3/4 - 93
47 1/4 - 50 1/4
74 3/4 - 79
67 3/4 - 72
48" + 48"
108 1/2 -114 1/4
27 3/4 - 29 1/4
99 3/4 – 105
54 1/4 - 57 1/4
84 1/2 - 88 3/4
77 1/2 - 81 3/4
7 inch Ø
6" Length
23 1/2 - 29 1/4
5 - 6 1/2
23 3/4 - 29
10 1/4 - 13 1/4
22 3/4 - 27
15 1/4 - 19 1/2
12" Length
29 1/4 - 35
6 1/2 - 8
29 - 34 1/4
13 1/4 - 16 1/4
27 - 31 1/4
19 1/2 - 23 3/4
18" Length
35 - 40 3/4
8 - 9 1/2
34 1/4 - 39 1/2
16 1/4 - 19 1/4
31 1/4 - 35 1/2
23 3/4 - 28
24" Length
40 3/4 - 46 3/4
9 1/2 - 11 1/4
39 1/2 - 44 1/2
19 1/4 - 22 1/4
35 1/2 - 39 3/4
28 - 32 1/4
48" Length
64 - 69 3/4
15 3/4 - 17 1/2
60 1/4 - 65 1/2
54 - 57
52 1/2 - 56 3/4
45 - 49 1/4
24" + 12"
50 3/4 - 56 1/2
12 1/4 - 13 3/4
48 1/4 - 53 1/2
1 1/2 - 4 1/2
42 3/4 - 47
35 1/4 - 39 1/2
48" + 12"
74 - 79 3/4
18 1/2 - 20
69 - 74 1/4
36 1/4 - 39 1/4
59 3/4 - 64
52 1/4 - 56 1/2
48" + 18"
79 3/4 - 85 1/2
20 - 21 1/2
74 1/4 - 79 1/2
39 1/4 - 42 1/4
64 - 68 1/4
56 1/2 - 60 3/4
48" + 24"
85 1/2 - 91 1/4
21 1/2 - 23 1/4
79 1/2 - 84 3/4
42 1/4 - 45 1/4
68 1/4 - 72 1/2
60 3/4 - 65
48" + 24" + 12"
95 1/2 -101 1/4
24 1/4 - 25 3/4
88 1/4 - 93 1/2
47 1/2 - 50 1/2
75 1/2 - 79 3/4
68 - 72 1/4
48" + 48"
108 3/4 -114 1/2
27 3/4 - 29 1/4
100 1/4 -105 1/2
54 1/4 - 57 1/4
85 1/4 - 89 1/2
77 3/4 - 82
8 inch Ø
6" Length
23 3/4 - 29 1/2
5 - 6 1/2
24 1/4 - 29 1/2
10 1/4 - 13 1/4
23 1/2 - 27 3/4
15 3/4 - 20
12" Length
29 1/2- 35 1/4
6 1/2 - 8
29 1/2 - 34 3/4
13 1/4 - 16 1/4
27 3/4 - 32
20 - 24 1/4
18" Length
35 1/4 - 41
8 - 9 3/4
34 3/4 - 40
16 1/4 - 19 1/4
32 - 36 1/4
24 1/4 - 28 1/2
24" Length
41 - 47
9 3/4 - 11 1/4
40 - 45
19 1/4 - 22 1/4
36 1/4 - 40 1/2
28 1/2 - 32 3/4
48" Length
64 1/4 - 70
15 3/4 - 17 1/2
60 3/4 - 66
31 1/4 - 34 1/4
53 1/4 - 57 1/2
45 1/4 - 49 1/2
24" + 12"
51 - 56 3/4
12 1/4 - 13 3/4
48 3/4 - 54
24 1/2 - 27 1/2
43 1/2 - 47 3/4
35 3/4 - 40
48" + 12"
74 1/4 - 80
18 1/2 - 20
69 1/2 - 74 3/4
36 1/2 - 39 1/2
60 1/2 - 64 3/4
52 1/2 - 56 3/4
48" + 18"
80 - 85 3/4
20 - 21 3/4
74 3/4 - 80
39 1/2 - 42 1/2
64 3/4 - 69
56 3/4 - 61
48" + 24"
85 3/4 - 91 1/2
21 3/4 - 23 1/4
80 - 85 1/4
42 1/2 - 45 1/2
69 - 73 1/4
61 - 65 ¼
48" + 24" + 12"
95 3/4 - 101 1/2
24 1/4 - 25 3/4
88 3/4 - 94
47 1/2 - 50 1/2
76 1/4 - 80 1/2
68 1/4 - 72 1/2
48" + 48"
109 - 114 3/4
27 3/4 - 29 1/2
100 3/4 - 106
54 1/2 - 57 1/2
86 - 90 1/4
78 - 82 1/4
The best place to install the adjustable length is immediately below the top elbow.
The adjustable length can then be adjusted to give you the offset you require.
NOTE: An adjustable length can not be used immediately above an elbow, there must be a
straight length below it.
