EXCEL TECHNICAL SPECIFICATIONS
Materials:
Exterior (casing): .015” Type 434 Stainless Steel
Interior (flue): .015” Type 304 Stainless Steel
Insulation: ICC “Thermoplus” Blanket
Inside Diameter
5 Inch
6 Inch
7 Inch
8 Inch
Outside diameter
7”
8”
9”
10”
Weight/Foot (lb/ft.)
3.6
4.2
4.9
5.3
Clearance to combustibles
2” or as established by factory
built supports and firestops
Rough Opening Required
Round support (ERDS & ES)
10” X 10”
10” X 10”
11” X 11”
12” X 12”
Square support (ESS)
N/A
10” X 10”
11” X 11”
12” X 12”
Roof support (ERS)
11” X 11”
12” X 12”
13” X 13”
14” X 14”
Offset support (EOS)
11” X 11”
12” X 12”
13” X 13”
14” X 14”
Radiation shields
(ERS &ERSA)
11” X 11”
12” X 12”
13” X 13”
14” X 14”
Wall radiation shield
(EWRS)
10” X 10”
10” X 10”
11” X 11”
12” X 12”
Maximum Support Capacity
Round support (ERDS & ES)
65 feet
55 feet
50 feet
45 feet
Square support (ESS)
N/A
55 feet
50 feet
45 feet
Roof support (ERS)
65 feet
55 feet
50 feet
45 feet
Wall support (EWS)
50 feet
44 feet
37 feet
35 feet
Offset support (EOS)
35 feet
30 feet
27 feet
25 feet
Radiation shields must be used at all floor joist and ceiling areas
