MACHINE COMPONENTS
26
.
Direction button
27
.
ECO display
28
.
Direction display
29
.
Timer
30
.
Detergent adjusting display
31
.
Signal
32
.
Battery meter
33
.
Vacuum motor display
34
.
Solution ow adjusting display
35
.
1-Step starting button
36
.
ECO Button
37
.
Detergent adjusting button
38
.
Solution ow adjusting button
39
.
Vacuum motor starting button
40
.
Drain hose, recovery tank
41
.
Vacuum hose
42
.
Drive motor
43
.
Adjusting knob, Squeegee
44
.
Filter assembly
,
Solution tank drain
26 27 28 29 30 31 32
33
34 35
36 37 38 39
40
41
42
43
44
