ICE Games SNACK ATTACK - Page 35

35
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2063X - COUNTER HARNESS
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
12 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
Prize
Counter
5v
Coin
Counter
5v
Red Black
Black Red
brown/white orange brown
PCNTR
+5v
CCNTR
P8
Counter
TO MAIN PCB
#2558 #2558 #2558 #2558
10 "
6 "
* USE NEW LARGE 5V COUNTERS
1 2 3
3 PIN PLUG #2206 SOLID PIN #2100S
