ICE Games SNACK ATTACK - Page 36

36
D C
B A
4321
D C
B A
4321
DATE
7/9/01
DESCRIPTION
#CS2064X - BALLAST POWER EXTENTION
DRAWN BY
MMARTIN
FILENAME
CS.VSD
PAGE
13 OF 16
REVISED
2/6/02
TITLE
SNACK ATTACKER
3 PIN CAP #2288 FEMALE #2102
1 2 3
#8173 - CABLE 3 COND SVT
BLACK GREEN WHITE
2513
#PC20217
GREEN/YELLOW
8 "
To Ballast
To Transformer
1 2
2 PIN PLUG #2103 SOLID PIN #2100S
BLACK
WHITE
